Variable angle

windshield support

Automotive Laminated

Used for:

Optical distortion test and double image test



Conforms to:

ECE-R43 regulations Annex 3 paragraph 9.2 and ECE-R43 Annex 3 paragraph 9.3.1.1.



Principe of operation:

This support stand for windshield is made of steel tube and permits horizontal adjustment, inclination to 90°, as well as rotation of the safety glass. This is necessary to view the whole surface of the glass. There is ball bearing in the horizontal pivot to 360°.



It consists of a frame mounted on wheels which can be blocked, and of four supports to fix the safety glass.

There is an analogical horizontal angle indicator and digital installation inclination angle display.

The test must be done in the installation angle.



Features:

• It can be used for glass of all sizes thanks to the support sticks.
• The stand allows a completely unhindered view on the glass.



Technical characteristics:

Analogical horizontal angle indication

Digital installation angle display

Other sizes available.
